– Perimeter lift with thermal break 125mm –
Performance
Thermal Transmission Coefficient Uw
1.6 W/m²K
Acoustic Attenuation Coefficient
40dB
Energy Class
Class A
Air Permeability (EN 1026)
Class 3
Watertightness (EN 1027)
Class 7A
Wind resistance (EN 12211)
Class C5
Minimum rim width
125 mm
Minimum Rim View
50 mm
Minimum view Rim + Sash
145 mm
Maximum Height
3300 mm
Maximum Length
3200 mm
Maximum Weight
400 Kg
Bit height
22 mm
Glass filling
35.5 mm
Thermal break
14.8/24 mm
League
6063
General thickness
1.8 mm
Types of opening
